Description


SPECIFICATIONS :

Electrical Characteristics
Maximum Power Pmax (WP)300wp305wp310wp315wp320wp325wp330wp
Open Circuit Voltage (Voc)45.1 V45.15 V45.35 V45.5 V45.6 V45.75 V45.85 V
Optimum Operating Voltage (Vmp)36.20 V36.42 V36.65 V36.85 V37.12 V37.45 V37.76 V
Optimum Operating Current (Imp)8.3 A8.38 A8.46 A8.55 A8.63 A8.69 A8.75 A
Short Circuit Current (Isc)8.8 A8.9 A9.01 A9.06 A9.1 A9.14 A9.21 A
Fill Factor75.59%75.90%75.87%76.41%77.12%77.72%78.15%
Fill Factor75.59%75.90%75.87%76.41%77.12%77.72%78.15%
Module Efficiency15.46%15.72%15.98%16.23%16.49%16.75%17.01%
Operating Conditions-40℃ to 85℃ at 85% RH
Temp Co-eff for Voc/℃ (B)-0.35%
Temp Co-eff for Isc/℃ (a)-0.05%
Temp Co-eff for Power/℃ (y)-0.40%
NOCT45 ± 2℃
Maximum System Voltage1000 V
Mechanical Characteristics
Weight23Kg
Module Dimension (W)X(H)X(T)(1956x992x35)mm
Static Load Wind / Snow2400 Pa / 5400 Pa
Fire RatingClass C
